65° Tilt Compensation – 3D Electronic Compass

ER-EC-395P:
1. Heading accuracy 1°;
2. Tilt range ±65°, accuracy 0.1°;
3. With hard magnetic, soft magnetic and tilt compensation.

65° Tilt Compensation – 3D Electronic Compass

65° Tilt Compensation - 3D Electronic Compass

Get Price Now

    65° Tilt Compensation – 3D Electronic Compass

    Product Description

    It is a high-precision three-dimensional electronic compass that uses hard and soft iron calibration algorithms to provide high-precision heading information up to an inclination of 65°. It has the characteristics of small volume and low power consumption, and is more suitable for a power volume sensitive measurement system.

    The output precise attitude of carrier can be used in a full attitude rotation system. This product has hard magnetic, soft magnetic and dip angle compensation, the compass output after calibration of high precision measurement value. The patented three-axis fluxgate uses the CPU to calculate the heading in real time, and the three-axis accelerometer compensates for the heading angle, which can provide accurate heading and obtain data even in extremely harsh environments. With the characteristics of small size and low power consumption, it is widely used in many fields such as petroleum logging, antenna pointing, vehicle navigation, attitude system and so on.

    Features

    Measurement range 0~360°

    Heading accuracy 0.5°, tilt range ±65°

    Industrial grade design

    Input voltage DC 5V

    Wide temperature working -40~+85℃

    With hard magnetic, soft magnetic and tilt compensation

    Baud rate 2400~115200 (adjustable)

    Working current 40mA

    IP67 protection level

    Output RS232/RS485/TTL/MODBUS (optional)

    Small volume (55*37*24mm) (customizable)

    Applications

    Individual combat equipment

    Satellite solar antenna positioning

    Low AGV car

    Mining machinery, oil logging equipment

    Medical equipment

    Gimp leveling

    UAV positioning and navigation

    Tilt based monitoring

    Various construction machinery angle control

    Inspection of bridges and dams

    Specifications

    Compass heading parameter Heading accuracy 0.5° (pitching<40°)
    0.7° (pitching<55°)
    1° (pitching<65°)
    Resolution 0.01°
    Repeatability 0.1°
    Compass tilt parameter Pitch accuracy 0.1°
    Roll accuracy 0.1° for pitch< 65º
    Dip resolution 0.01°
    Tilting range ±65°
    Calibration Hard iron calibration Yes
    Soft iron calibration Yes
    Tilt calibration Yes
    Physical property Size L55xW37xH24 (mm)
    Weight 75g
    Rs-232/RS485 interface connector 5 pin
    Characteristics of interfaces Startup delay <50ms
    Maximum sampling rate 50 times per second
    RS-232 communication rate 2400~19200 baud rate
    RS-485 communication Optional
    TTL communication Optional
    Output format Binary high performance protocol
    Power supply Support the voltage DC+5V
    Current (maximum) 40mA
    Working mode 35mA
    Environment Storage temperature -40℃~+125℃
    Working temperature -40℃~+85℃
    Vibration resistance 3000g

    FAQ

    1. What are the quotation methods?

    If you have DHL or Fedex account, we can quote EXW price, otherwise CIF or FOB price.

    2. Are there any discounts?

    After we submit the sample price, if more quantity is needed, we will quote the bulk price.

    3. How long will it take to deliver the goods after placing the order?

    For sensors, parts and modules: in stock-one week; no stock-2-4 weeks; For systems, generally, 8-12 weeks.

    4. How to deal with the quality problems?

    After confirming that the product has quality problems, we will replace it for you free of charge in the shortest possible time.

    If interested in ER-EC-395P 65° Tilt Compensation 3D Electronic Compass – Digital Type, pls contact us: info@ericcointernational.com
