Small Size Fiber Optic Gyroscope

ER-FOG-60 (0.06 ~ 0.5º/h)
1. Bias stability: 0.06 ~ 0.5º/h;
2. Small size: Φ60mm×32mm;
3. Light weight: ≤120g.

Small Size Fiber Optic Gyroscope

small-size-fiber-optic-gyroscope

Get Price Now

    ER-FOG-60 Small Size Fiber Optic Gyroscope

    ER-FOG-60 small size fiber optic gyroscope is an important angular rate sensor, which has the characteristics of long life, fast start up, high precision, lower power consumption, wide dynamic range and so on. It plays an important role in aerospace, weapon navigation, platform stabilizer, UAV and other fields.

    Applications

    Small IMU、INS、missile seeker

    Servo tracking、photoelectric pod、drone

    Specifications

    Items Unit ER-FOG-60A ER-FOG-60B ER-FOG-60C ER-FOG-60D
    Measuring range º/s -1000~+1000 -1000~+1000 -1000~+1000 -1000~+1000
    Zero offset stability º/h ≤ 0.06 ≤0.1 ≤0.3 ≤0.5
    Zero bias repeatability º/h ≤ 0.06 ≤0.1 ≤0.3 ≤0.5
    Random walk coefficient º/√h ≤ 0.006 ≤0.01 ≤0.03 ≤0.05
    Scale factor non-linearity ppm ≤ 50 ≤60 ≤70 ≤100
    Scale factor repeatability ppm ≤ 50 ≤ 60 ≤70 ≤100
    Scale factor asymmetry ppm ≤ 50 ≤60 ≤70 ≤100
    Start time s ≤1 ≤1 ≤1 ≤1
    Bandwidth Hz >200 >200 >200 >200
    Power supply V -5~+5 -5~+5 -5~+5 – 5~+5
    Power W ≤18 ≤18 ≤18 ≤18
    Operating temperature -45~+65 -45~+65 -45~+65 -45~+65
    Storage temperature -45~+85 -45~+85 -45~+85 -45~+85
    Vibration / 2g (RMS), 20Hz~2000H
    Shock / 40g, 1ms 40g, 1ms 40g, 1ms 40g, 1ms
    Output method / RS-422 RS-422 RS-422 RS-422
    Connector / J30J-15TJL/Color line
    Dimensions mm Φ60×3 Φ60×3 Φ60×3 Φ60×3

    Note: Unfilled dimensional tolerances are performed in accordance with GB/T 1804-2000 Class C.

    FAQ:

    1. What are the quotation methods?

    If you have DHL or Fedex account, we can quote EXW price, otherwise CIF or FOB price.

    2. Are there any discounts?

    After we submit the sample price, if more quantity is needed, we will quote the bulk price.

    3. How long will it take to deliver the goods after placing the order?

    For sensors, parts and modules: in stock-one week; no stock-2-4 weeks; For systems, generally, 8-12 weeks.

    4. How to deal with the quality problems?

    After confirming that the product has quality problems, we will replace it for you free of charge in the shortest possible time.

    If interested in Small Size Fiber Optic Gyroscope, pls contact us: info@ericcointernational.com
