High Accuracy MEMS Accelerometer

High Accuracy MEMS Accelerometer

ER-MA-5 (Alternative of MS1000)(20~150ug):
1. Bias stability (Allan Curve) 5 ug;
2. Bias stability (1s Standard Deviation)(1σ)<20ug;
3. Bias month repeatability 200ug.

High Accuracy MEMS Accelerometer

High Accuracy MEMS Accelerometer

Get Price Now

    Share to:

    ER-MA-5 High Accuracy MEMS Accelerometer (Alternative of MS1000)

    Accelerometer is an inertial sensor, which can measure the linear acceleration due to gravity. MEMS accelerometer has the characteristics of small volume, light weight and low energy consumption that can be widely used in vibration detection, attitude control, security alarm, consumer applications, motion recognition and status recording. Accelerometers are combined with gyroscopes and magnetometers to create IMU (inertial measurement units).

    Applications

    Inertial measurement: inertial guidance, overload measurement, combined navigation
    Tilt measurement: antenna attitude, platform measurement, dip test
    Vibration measurement: mechanical equipment, bridge dam, safety test

    Specifications

    Axis

    X

    X

    X

    X

    Unit

    Range

    2-10

    30-50

    70-100

    150-200

    g

    Bandwidth

    100.00

    100

    100

    100

    Hz

    Bias Stability (Allan Curve)

    <5

    <10

    <20

    <30

    ug

    Bias Stability (1s Standard Deviation) (1σ)

    <20

    <50

    <100

    <150

    ug

    Bias Month Repeatability

    100-300

    300-500

    1000

    1000

    ug

    Bias Temp Coefficient

    <10

    <50

    <100

    <200

    ug/℃

    Bias Temp  Hysteresis

    <0.5

    <1

    <3

    <5

    mg

    Factor Scale Non-linearity

    <500

    <1000(2000@50g)

    <1000

    <2000(3000@50g)

    ppm

    Factor Scale Month Repeatability

    <300

    <300

    <300

    <300

    Ppm

    Factor Scale Temp Coefficient

    10

    10

    10

    10

    ppm/℃

    Class II Non-linearity Coefficient

    <100

    <100

    <100

    <100

    ug/g2

    Factor Scale

    4000000-800000

    200000-150000

    100000-80000

    50000-40000

    Lsb/g

    Resolution

    5

    10

    25

    50

    ug

    Start Time

    <1

    <1

    <1

    <1

    s

    Sampling Rate

    1500

    1500

    1500

    1500

    Hz

    Shock(charged)

    10000

    10000

    10000

    10000

    g

    Shock(uncharged)

    10000

    10000

    10000

    10000

    g

    Vibration Rectification Error (6grms)

    /

    <0.4

    <0.15

    <0.05

    mg/grms

    Operation Temp

    -40~+80

    Voltage

    5±0.25

    5±0.25

    5±0.25

    5±0.25

    V

    Current

    <15

    <15

    <15

    <15

    ma

    Interface

    SPI

    SPI

    SPI

    SPI

    SPI
