High-precision RTK Positioning and Orientation Module

ER-GM-442 Features:
1. 30×40mm size, single-sided surface mount module;
2. RTK initialization time is better than 5s, support RTK solution above 20km;
3. 10Hz high data output rate.

High-precision RTK Positioning and Orientation Module

Get Price Now

    ER-GM-442 High-precision RTK Positioning and Orientation Module

    Introduction

    ER-GM-442 High-precision RTK Positioning and Orientation Module uses a new generation of full-system, full-frequency and high-precision SoC chip-Nebulas-II, which can support 432 super channels. Its powerful processing capability and embedded JamShield anti-interference technology can simultaneously track BDS, GPS, GLONASS, Galileo, and SBAS, QZSS and other system satellite signals even anti-jamming processing.

    Through the calculation with Xingtong’s enhanced RTK engine, it takes full advantage of multiple systems to achieve high-performance, high-reliability centimeter-level positioning accuracy and high-precision orientation based on low power consumption and low cost solutions. Using instant heading technology, real-time dynamic high-precision fast orientation of mobile base stations with variable baseline length is achieved. ER-GM-442 integrates the on-board MEMS chip and U-Fusion integrated navigation algorithm, which can effectively solve the situation where the positioning results are interrupted due to the loss of satellite signals. It can provide continuous high quality in complex environments such as buildings, tunnels, viaducts and shade positioning results.

    Features

    Whole system high-precision RTK surface mount module, RTK centimeter-level high-precision positioning and orientation module

    30×40mm size, single-sided surface mount module

    RTK initialization time is better than 5s, support RTK solution above 20km

    10Hz high data output rate

    Adaptable to low-cost active ceramic antennas

    Onboard MEMS integrated navigation, support U-Fusion tight integrated navigation technology

    Specifications

    Aisle 432 channels, based on Nebulas-II chip
    Frequency GPS L1, BDS B1, GLONASS L1, Galileo E1, QZSS L1
    Single Point Positioning (RMS) Plane: 1.5m  Elevation: 3.0m
    DGPS (RMS) Plane: 0.4m  Elevation: 0.8m
    RTK (RMS) Plane: 1.0cm+1ppm  Elevation: 1.5cm+1ppm
    Speed accuracy (RMS) 0.03m/s
    Timing accuracy (RMS) 20ns
    Orientation accuracy (RMS) 0.2°/1m baseline
    Time to first fix (TTFF) Cold start <40s
    Initialization time <5s (typical value)
    Initial reliability >99.9%
    Recapture time <1s
    Data Format NMEA-0183, Unicore
    Differential data RTCM 2.3/3.0/3.2
    Positioning update rate 10Hz
    Power consumption 1.4W
    Physical properties
    Size 30×40×4 mm
    Weight 8g
    Operating temperature -40°C~+85°C
    Storage temperature -55°C~+90°C
    Humidity 95% non-condensing
    Vibration GJB150.16-2009, MIL-STD-810
    Shock GJB150.18-2009, MIL-STD-810
    Electrical index
    Voltage 3.3VDC+5%/-3%
    Voltage ripple 100mVp-p (max)
    LNA power output 4.75~5.0V, 0~100mA
    Power consumption 1.4w
    Function interface
    3xUART, 1xI2C, 1xSPI (LV-TTL), 1xPPS (LV-TTL), 1xEvent input

    FAQ:

    1. What are the quotation methods?

    If you have DHL or Fedex account, we can quote EXW price, otherwise CIF or FOB price.

    2. Are there any discounts?

    After we submit the sample price, if more quantity is needed, we will quote the bulk price.

    3. How long will it take to deliver the goods after placing the order?

    For sensors, parts and modules: in stock-one week; no stock-2-4 weeks; For systems, generally, 8-12 weeks.

    4. How to deal with the quality problems?

    After confirming that the product has quality problems, we will replace it for you free of charge in the shortest possible time.

    If interested in High-precision RTK Positioning And Orientation Module, pls contact us: info@ericcointernational.com
