Voltage Type Plane Multi-direction Tilt Switch
It is a high-performance on/off output multi-directional digital tilt switch, which can measure the tilt angle in any direction of 360 degrees horizontally. When the tilt value is greater than the preset tilt threshold, a switch signal will be output to drive the solenoid valve. It should be mentioned that the alarm threshold has been calibrated at the factory, and the operator can also set it by himself.
The tilt switch integrates an imported core unit and is used for horizontal security alarm and platform level monitoring related industries. The product adopts a transistor output circuit, which can drive a solenoid valve to close the hydraulic system, buzzer, alarm lamp, etc. It can automatically warn workers of safe construction, product design accuracy, temperature and linear compensation, and integrate comprehensive protection functions such as short circuit, instantaneous high voltage, polarity, and surge, which is suitable for various harsh industrial environments.
Double axis tilt monitoring
Full range accuracy 0.1°, resolution 0.01°
Alarm threshold can be set by the user
Input voltage DC 9~36V
Wide temperature working -40~+85℃
High vibration resistance >3500 g
Industrial grade design
IP67 protection level
Switching value output (voltage), RS232 output meantime
Volume (55*37*24mm) (Customizable)
Satellite solar antenna positioning
Tractor, deep tillage machinery
Mining machinery, oil logging equipment
Hydraulic lifting platform
Tilt based monitoring
Various construction machinery angle control
Inspection of bridges and dams
|Measuring axis||/||Z axis||/|
|Alarm axis||/||Z axis||/|
|Frequency response||DC response||100||Hz|
|Power on startup time||/||0.5||S|
|Output signal||Switching value (voltage) output, can be RS232, TTL optional at the same time|
|Mean time between failures||≥55000 hour/time|
|Shock resistance||3500g, 0.5ms, 3times/axis|
|Cable||Standard 1.5m length, wear-resistant, oil-proof, wide temperature, shielding cable 5*0.3mm2|
|Weight||75g (without packing)|
1. What are the quotation methods?
If you have DHL or Fedex account, we can quote EXW price, otherwise CIF or FOB price.
2. Are there any discounts?
After we submit the sample price, if more quantity is needed, we will quote the bulk price.
3. How long will it take to deliver the goods after placing the order?
For sensors, parts and modules: in stock-one week; no stock-2-4 weeks; For systems, generally, 8-12 weeks.
4. How to deal with the quality problems?
After confirming that the product has quality problems, we will replace it for you free of charge in the shortest possible time.
If interested in ER-TS-16 Voltage Type Plane Multi-direction Tilt Switch, pls contact us: firstname.lastname@example.org
