Single Axis FOG Gyroscope

Features:
1. Small volume, light weight, low power consumption;
2. Fast start-up, simple operation, convenient to use;
3. High precise measurement/navigation system and servo system.

Send Inquiry
Single Axis FOG Gyroscope

Single Axis Fiber Optic Gyroscope

NS series Fiber optic gyroscope is designed with concept of traditional fiber optic gyroscope. Adapting matured fiber optic gyroscope manufacturing technology, NS series fiber optic gyroscope with characteristics of small volume, light weight, low power consumption, fast start-up, simple operation, convenient to use etc.


NS series FOG use the principle of interference of Sagnac, make the laser as light source, light path of loop type is constructed by fiber, and inspect phase differences of two routes laser beam, the phase differences was caused by two beam (two beam from the pro and con hour hand was transmitted along optical fiber) rotated along with fiber loop, then will calculate the rate of angular speed of the optical gyroscope.


Application:

  • Optical pod/Flight control platform

  • SINS / IMU

  • Platform stabilization device

  • Position marker control system

  • North finding instrument

  • High precise measurement/ navigation system and servo system




No.

Parameter

NS-501

 Single   axis

NS-701

Single axis

NS-D851

Single axis

NS-H851

Single axis

Unit

1

Measurement   range

-1000+1000

-1000+1000

-800+800

-500+500

(º)/s

2

Bias stability

0.31

0.10.5

0.050.1

≤0.05

(º)/h

3

Bias   repeatability

0.31

0.10.5

0.050.1

≤0.05

(º)/h

4

Scale factor non-linearity (1σ)

≤100

≤100

≤100

≤50

ppm

5

Scale factor misalignment (1σ)

≤100

≤100

≤100

≤50

ppm

6

Scale factor repeatability (1σ)

≤100

≤100

≤100

≤50

ppm

7

Power supply

±5

Single +5

Single +5

Single +5

V

8

Bandwidth

≥500

≥500

≥500

≥500

Hz

9

Run-up time

5

5

5

5

s

10

Output format

RS422

RS422

RS422

RS422


11

External interface

15PIN

9 PIN

21PIN

21PIN


12

Operating temperature

-40+60

-40+60

-40+60

-40+60

13

Vibration

6.06, 202000

6.06, 202000

6.06, 202000

6.06, 202000

g(RMS), Hz

14

Dimension

52×52×40

70×70×29

78.5×78.5×35

78.5×78.5×35

mm³

15

Weight

≤170

≤200

≤300

≤300

g

16

Threshold value

≤0.3

≤0.5

≤0.05

≤0.05

(º)/h

17

Random walking coefficient

≤0.02

≤0.02

≤0.005

≤0.005

(º)/h½

18

Impact strength

100, 68

100, 68

100, 68

100, 68

G, ms

19

Power consumption

≤4

≤4

≤4

≤4

W

20

Random walking

5

5

5

5

s


No.

Parameter

NS-98

Single axis

NS-951

Single axis

NS-F120

Single axis

Unit

1

Measurement   range

-300+300

-1000+1000

-500+500

(º)/s

2

Bias stability

0.030.05

0.20.5

≤0.0050.01

(º)/h

3

Bias   repeatability

0.030.05

0.20.5

≤0.01

(º)/h

4

Scale factor non-linearity (1σ)

≤50

≤100

≤20

ppm

5

Scale factor misalignment (1σ)

≤50

≤100

≤20

ppm

6

Scale factor repeatability (1σ)

≤50

≤100

≤20

ppm

7

Power supply

Single +5

Single +5

Single +5

V

8

Bandwidth

≥500

≥500

≥500

Hz

9

Run-up time

5

5

5

s

10

Output format

RS422

RS422

RS422


11

External interface

9 PIN

9 PIN

15 PIN


12

Operating temperature

-40+60

-40+60

-40+60

13

Vibration

6.06, 202000

6.06, 202000

6.06, 202000

g(RMS), Hz

14

Dimension

98×98×30

118×118×35

120×120×39

mm³

15

Weight

≤280

≤650

≤700

g

16

Threshold value

≤0.03

≤0.2

≤0.01

(º)/h

17

Random walking coefficient

≤0.005

≤0.02

≤0.002

(º)/h½

18

Impact strength

100, 68

100, 68

100, 68

G, ms

19

Power consumption

≤4

≤4

≤5

W

20

Random walking

5

5

5

s
